Detail TOA ZA- 1240SS ( Mixer Amplifier With Selector )
TOA ZA- 1240SS adalah power mixer kapasitas daya output 240 watt, dilengkapi dengan 5 Zone Selector , berfungsi untuk mempermudah pembagian Zona Speaker ,
perbaduan antara mixer & Amplifier TOA ZA- 1240 cocok dipergunakan untuk kantor , mall, supermarket, sekolahan , masjid , musholla, gereja, Pergudangan , Pabrik.
Specifications
Power Source AC 230 V 50/ 60 Hz
Rated Output 240 W
Power Consumption 252 W
Frequency Response 50-18, 000 Hz , + / - 3 dB
Distortion Less than 0.3% at 1 kHz, 1/ 3 Rated Power
Inputs MIC 1, MIC 2, MIC 3 -52 dBV ( 2.5 mV) , 600 Ohm, Unbalanced, Equivalent to Phone Jack
AUX 1, AUX 2 -10 dBV ( 316mV) , 10 kOhm, Unbalanced, RCA Pin Jack
Outputs Direct Line 4-16 Ohm, 42 Ohm ( 100 V)
Speaker Selector 5-zone selector ( all zones simultaneously selectable, plug in screw / 1 all call
Pre Out 0 dBV ( 1.0V) , 600 Ohm, Unbalanced RCA Pin Jack
S/ N Ratio Over 65 dB( MIC1- MIC3) , Over 75 dB ( AUX 1 - AUX2)
Tone Controls Bass: + / - 10 dB at 100 Hz, Treble: + / - 10 dB at 10 kHz
Muting MIC 1 over rides other input signals with 0 - 40 dB attenuation by voive switch of MIC 1 input level
Indicators Power LED, Signal LED
Finish Panel: ABS Resin, Black/ Case: Steel Plate, Black
Dimensions 420 ( W) x 110( H) x 384 ( D) mm
Weight 12.8 kg
Accessory AC power cord ( 1pc)
